| 型號： | SC8815A |
| 廠 商： | |
| 品牌/商標: | SOUTHCHIP/南芯 |
| 產(chǎn)品類別： | 南芯/SOUTHCHIP- |
| 聯(lián)系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
科瑞芯供應 SC8815A 南芯同步降壓升壓充電器控制器
Features
● Buck-Boost Battery Charger for 1 to 6 Cell Batteries
● Charging Management including Trickle Charge, CC Charge, CV Charge and Charge Termination
● Buck-Boost Reverse Discharging Mode
● Wide VBAT Range: 2.7 V to 36 V, 40V sustainable
● Wide VBUS Range: 2.7 V to 36 V, 40V sustainable
● I2C Programmable Charging Current and Voltage
● I2C Programmable Discharging Output Voltage
● I2C Programmable Input / Output Current Limit
● I2C Programmable Switching Frequency
● High Efficiency Buck-Boost Conversion
● 10-bit ADC resources
● Charging Status Indication
● Event Detections, including Automatic Adapter Insert and Automatic Load Insert Detection
● Power Path Control
● Under Voltage Protection, Over Voltage Protection, Over Current Protection, Short Circuit Protection and Thermal Shutdown Protection
● QFN-32 Package
Applications
● Power Bank with Fast Charge Function
● USB Power Delivery
● Type C Hub
● Industrial Power Supplies
