| 型號： | LPQ3988H |
| 廠 商： | |
| 品牌/商標: | LPSemi/微源半導體 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
微源 LPQ3988H 汽車低噪聲低壓差穩壓器
Features
● Compliance with automotive application
● AEC-Q100 certification:
Device temperature Level 1: -40℃ to 125℃
● Wide input voltage range: 2.0V to 5.5V
● High output voltage accuracy: ±1.5%(Typ)
● Ultra-high PSRR: 98dB @ 20mA/1kHz
● Ultra-low noise: 10μVRMS @ 20mA
● Low current consumption: 24μA (Typ)
● Low dropout voltage:
165mV at 250mA (VOUT = 1.8V)
480mV at 500mA (VOUT = 1.8V)
● Integrated over-current protection
● Thermal shutdown
● Active-high EN pin
● Robust ESD capability:
Human Body Model: 4 kV
Charged Device Model: 1 kV
● Package: SOT23-5
● RoHS Compliant and 100.00% Lead (Pb)-Free
Applications
● Automotive rear camera
● ADAS
● Image sensor power supply
● Automotive infotainment
● Automotive body electronics
