微源代理商供應 LP4020B6F 2A鋰離子電池充電器
General Description
The LP4020 is a 2A Li-ion battery charger. It utilizes a 600KHz synchronous buck converter topology to reduce power dissipation during charging. Low power dissipation and internal MOSFET allow a physically small charger that can be embedded in a wide range
of handheld applications.
The LP4020 includes complete charge termination circuitry, automatic recharge and ±1% 4.2V float voltage.
Additional features include shorted cell detection; temperature qualified charging and overvoltage protection.
The LP4020 is available in a low profile SOT23-6/ESOP8 package.
Features
◆ Input voltage range 4.5V~5.5V
◆ Dynamic input current allocation for maximum charging rate
◆ 2A Maximum Charge Current
◆ No External MOSFETs and Blocking Diode Required
◆ Efficiency up to 90%
◆ Constant-Current/Constant-Voltage Charger
◆ Over Current Protection
◆ Consumption Available in SOT23-6/ESOP8
◆ RoHS Compliant and 100% Lead (Pb)-Free
Application
◆ Portable Media Players
◆ Cellular and Smart mobile phone
◆ PDA/DSC
◆ Handheld Battery-Powered Devices
◆ Handheld Computers
◆ Charging Docks and Cradles
