| 型號： | LP6470 |
| 廠 商： | |
| 品牌/商標: | 微源半導體 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
微源原裝 LP6470 2芯鋰電池供電芯片
General Description
The LP6470 contains an independent 500KHzconstant frequency, current mode, PWM step-down converters. The converter integrates a main switch anda synchronous rectifier for high efficiency without an external Schottky diode. The LP6470 is ideal for powering portable equipment that runs from a 2cell Lithium-Ion (Li+) battery. The converter can supply 2000mA of load current from a 4.5V to 16V input voltage. The output voltage can be regulated as low as 0.8V.
The LP6470 is available in a SOT23-6 package and is rated over the -40°C to 85°C temperature range.
Features
◆ Input Voltage Range: 4.5V to 16V
◆ Output Voltage Range: 0.8V to 12V
◆ 2000mA Load Current on Channel
◆ Up to 96% Efficiency
◆<10uAShutdown Current
◆ 500KHz Switching Frequency
◆ Short Circuit Protection
◆ Thermal Fault Protection
◆ SOT23-6 Package
◆ RoHS Compliant and 100％ Lead (Pb)-Free
