General Description

The G920 is a three terminal positive voltage regulator made using the CMOS process. The G920 can work in a wide operation range from 6V to 25V. The quiescent current is small even at high input voltage. The typical current consumption is about 4.5μA. It is very suitable for the battery-powered portable equipment, especially the keep-alive system. The G920 can provide the higher performance and a longer battery service life.

Features

■ Low current consumption (typically 4.5μA)

■ Output voltage accuracy ±2.5%

■ Drop-output voltage (typically)

2.5V @ 50mA loading

1.6V @10mA loading

■ Wide operating range (max 25V)

■ Internal over temperature protection

■ Excellent line regulation

Regulation <5mV @1mA loading VCC 6~25V

■ Good load regulation

Regulation: (typically)

40mV @VCC 7V loading 1μA to 30mA
