| 型號： | DP681TQFN46G-A0 |
| 廠 商： | |
| 品牌/商標: | PARADE/譜瑞科技 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
熱銷中 DP681TQFN46G-A0 譜瑞LCD時序控制器
Features
DisplayPort™ Input
Compliant to VESA® Embedded DisplayPort™ Standard 1.2
Supports VESA DPCD version 1.2
Supports 1-lane main link configuration and 2.7/1.62-Gbps data rate
Supports full link training, fast link training and no link training
Supports 18/24-bit RGB color format input
Supports DisplayPort™ standard SSC 0.5% down spreading
Content Protection
Supports eDP authentication: Alternate Scramble Reset (ASSR)
Panel Interface
Supports all sized panels up to one lane DisplayPort™ bandwidth limit, including HD (1366×768) and HD+ (1600×900) 6-bit panels
Supports Single bus, 3-pair, 6-bit mini-LVDS
Supports dynamic refresh rate (DRR), seamless Display Refresh Rate Switching (sDRRS) and nvDPS power saving modes
MiniLVDS interface pin swapping and internal data swapping for flexible TCON PCB design
Supports SINK additional SSC clock on miniLVDS interface: center spreading of 0.25% to 2.0%
TCON Interface
Supports dual gate pixel structure
Support special Z-Inversion pixel structure
Integrated programmable Gate Driver and Source Driver control signal generator
Fully programmable Gate Driver and Source Driver control I/O’s for GOP Applications.
Video Processing
CrystalFree technology – no external timing reference needed
Stores LUT contents in EEPROM to support gamma correction, color engine and FRC
Supports programmable BIST or Aging patterns
Backlight Control
Parade’s exclusive Smart-Backlight™1 feature for color and power optimization
Control Interface
I2C master for loading register initial values, or for expansion function
I2C slave for chip configuring, controlling and debugging
Integrated On-chip DC/DC switching regulator
Hardware driven power management
ESD HBM: 8000V for external connector pins, 7000V for all other pins; MM: 300V; CDM: 2000V
