| 型號： | PT6594 |
| 廠 商： | |
| 品牌/商標: | PCT/普誠 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
原裝芯片 普誠 PT6594 多功能LCD分段驅動器
FEATURES
● LCD drive output:
Common output: 4; Segment output: 42
Integrated Display data RAM (DDRAM): 42x4bit
● Integrated 3ch L ED driver circuit
● 3-wire Serial interface (SD, SCL, CSB)
● Segment/LED (Max. 3 ports) output mode selectable
● Segment/GPO (Max.27 ports) output mode selectable
● Support PWM generation from ext. or internal clock (Resolution: 8-bit mode/12-bit mode selectable)
● Integrated Oscillator circuit
● Integrated LCD Voltage generator circuit
● Support: 1/3 Bias, 1/3 or 1/4 Duty
● Support: 1/1 Bias, 1/1Duty (Static Driving)
● Bias: Static, 1/3
● Integrated regulator for LCD driver: 3.2, 3.3, 3.4, 4.4, 4.5, 4.6, 5.0V selectable
● Integrated buffer amp
● Support separate power supply for Logic (VDD) and LCD (VLCD)
● Low power consumption
● Support standby mode
● Integrated Power-On-Reset circuit (POR)
● No extermal components
● Support Blink function (Blink frequency 1.6, 2.0, 2.6, 4.0Hz selectable)
● Operating power supply: 1.8~3.6V
● LCD drive power supply: 3.3~5.5V
APPLICATIONS
● Telephone, FAX, Portable equipment (POS, ECR, PDA etc.)
● DSC, DVC, Car audio, Home electrical appliance, Meter equipment etc.
