微源原廠原裝 LP62610 同步升壓轉(zhuǎn)換芯片

General Description

The LP62610 device is a synchronous boost convertor with ultra-low quiescent current. It features a true-shutoff function that disconnects the input and output during shutdown and output short-circuit conditions.The LP62610 only consumes 1uA quiescent current under light load condition and can achieve up to 75% efficiency at 20uA load. It can achieve up to 93% efficiency at 200mA load from 3.3 V to 5V conversion.

Features

◆ Up to 95% efficiency

◆ Output to Input Disconnect at Shutdown Mode

◆ Shut-down current:<0.1uA

◆ Over Output Voltage Protection

◆ Over Current Protection

◆ Over Temperature Protection

◆ Internal Compensation of Soft-start

◆ 1.2MHz fixed frequency switching

Application

◆ Tablet, MID

◆ Smart Phone

◆ Power Bank
