| 型號： | LP5241 |
| 廠 商： | |
| 品牌/商標: | 微源半導體 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
微源 LP5241 雙通道5V6A負載開關芯片
General Description
The LP5241 is a load switch device with integrated dual channel.The device contains two independent N-type MOSFETs which can operate over an input voltage range from 0.6Vto 5.7V. It supports maximum continuous current up to 6A.The LP5241 has internal drivers to keep the MOSFETs in ON status. The turn-on slew rate can be programed via external capacitor on CT pins. The active-high enable pin can control every individual channel without impact the other one.These parts are available in space-saving 14-pins DFN package DFN-14L.
Application
◆ Notebook and PC
◆ Cell phone and PDAs
◆ USB or other peripheral ports
◆ Camera
