微源代理商供應 LP6462F 30V2A同步降壓轉換器
General Description
The LP6462 is a synchronous buck converter supporting up to 2A output current. The LP6462 employs an adaptive constant-on-time (COT) control scheme to achieve fast load transient response. The external components are minimized, requiring only one inductor, two resistors, and two capacitors.
The LP6462 supports both aluminum polymer capacitors and ceramic capacitors without extra compensation components.
The LP6462 integrates PFM (Pulse Frequency Modulation) operation, which helps maintain the system efficiency at light load. The LP6462 also integrates multiple protection functions, i.e., over-current protection (OCP), overtemperature protection (OTP), under-voltage lockout (UVLO), and short circuit protection (SCP).
The LP6462 is available in a small 6-pin 1.6mmx2.9mm SOT23-6 package.
Applications
◆ Industrial PC
◆ Network/digital video recorder (NVR/DVR)
◆ TV and TV box
◆ 12V Industrial bus applications
