| 型號： | LP6450M |
| 廠 商： | |
| 品牌/商標: | 微源半導體 |
| 產品類別： | 集成電路/IC- AC/DC電源芯片 |
| 聯系人: | 顏先生/William |
| 電話： | 0755-82170220,21001680 |
微源現貨 LP6450M 1.2MHz同步降壓轉換器
General Description
The LP6450X is a synchronous buck converter supporting up to 2A output current. The LP6450X employs an adaptive constant-on-time (COT) control scheme to achieve fast load transient response. The external components are minimized, requiring only one inductor, two resistors, and two capacitors. The LP6450X supports both aluminum polymer capacitors and ceramic capacitors without extra compensation components.The LP6450X integrates PFM (Pulse Frequency Modulation) operation, which helps maintain the system efficiency at light load. The LP6450X also integrates multiple protection functions, i.e., over-current protection (OCP), over-temperature protection (OTP), under-voltage lockout (UVLO), and short circuit protection (SCP). The LP6450X is available in a small 6-pin 1.6mmΧ2.9mm SOT23-6 package.
Applications
● Industrial PC
● Network/digital video recorder (NVR/DVR)
● TV and TV box
● 12V Industrial bus applications
