產(chǎn)品詳情

SGM6607AYTN6G/TR 電子元器件 SGMICRO 封裝SOT23-6 升壓轉(zhuǎn)換器IC

1.2A, S商場(chǎng)封裝的高壓B oost轉(zhuǎn)換器

一般的描述
The SGM6607A is an monolithic high voltage switching
regulator with integrated 1.2A, 40V power MOSFET.
This device can be configured in several standard
switching regulator topologies, including boost and
SEPIC. The device has a wide input voltage range 如
support applications with input voltage from multicell
batteries or regulated 5V, 12V power rails.
The SGM6607A operates at a 1. 1MHz switching
frequency, allowing the use of low profile inductors and
low-value ceramic input and output capacitors. E xternal
loop compensation components give the user flexibility
如optimize loop compensation and transient response.
The device has built-in protection features, such as
cycle-by-cycle over-current limit, soft start and thermal
shutdown.
The SGM6607A is available in Green TDF N-2x2 6AL
and TSOT-23-6 packages and is rated over the -40°C
to +85°C temperature range.
