微源 LPW5202FDB5F11 帶過電流保護的高側負載開關
Features
◆ 2.4V to 6V input voltage range
◆ Low on-state resistance to 70mΩ
◆ 30μA low current consumption
◆ Ultra-low shutdown current (<100nA)
◆ Fixed or adjustable current limit
- Fixed: 0.65A, 1.35A, 1.6A, 2.3A
- Adjustable: 200mA to 2.5A
◆ Under-voltage lockout
◆ Blocking reverse current
◆ Thermal shutdown protection
◆ Fast current limit response
◆ ESD Protection:
- Human Body Model: 4kV
- Charged Device Model: 0.5kV
◆ SOT23-5 Package
◆ UL Approved File No. E526435
Applications
◆ Notebook and PC
◆ Cell phone and PDAs
◆ USB or other peripheral ports
◆ Camera
